// Overlapper release 1.1 //
// Tool for creating overlapping action //
// copyright Dmitrii Kolpakov 2018 //
// //
// intro: https://vimeo.com/286860063 //
// purchase: https://gumroad.com/l/overlaper //
// //
// //
//***********************************************//
global proc OverlapperRelease()
{
optionVar -intValue animBlendingOpt 1;
if ((`window -ex OverlapperPanel`)==true)
deleteUI OverlapperPanel;
CleanUpProc;
string $window = `window -title "Overlapper 1.1"
-toolbox 1
-s 1
-menuBar 1
-widthHeight 172 133
OverlapperPanel`;
menu -l "Advanced" -to 0 aboutMenu;
menuItem -l "Debug mode" -cb 0 -ann "Don't delete Overlapping offset controls. Expert mode. Be careful" debMode;
menuItem -l "Bake on anim layer" -cb 0 -ann "Each new overlapping animation will be baked on new animation layer" onLayerMode;
menuItem -l "Adaptive scale" -cb 1 -ann "Overlap Scale parameter automaticly changes for distance between selected controls" adScaleMode;
menuItem -l "Create selection set" -cb 1 -ann "Create selection set of overlapped controls for last overlapper session" ovCrSelSet;
menuItem -l "CleanUp" -ann "Delete all Oveplapper stuff" -c CleanUpProc;
menu -l "Help" -to 0 helpMenu;
menuItem -l "Intro" -c hIntro;
menuItem -l "Tutorial" -c hTutorial;
columnLayout;
rowColumnLayout -nc 2 ;
text -label " Softness " -align "center" -ann "More animation velocity, less softness";
floatField -v 3 -w 10 -precision 2 timeShift;
text -label " Scale " -align "center" -ann "More Scale, more overlap apmlitude";
floatField -v 1.0 -w 10 -precision 2 globalScale;
rowColumnLayout -nc 1;
rowColumnLayout -nc 1;
checkBox -ann "Add wind animation on overlapped controls" -label " Wind" -v 0 -h 18 WindCheckBox;
setParent..;
setParent..;
rowColumnLayout -nc 2;
text -label " Scale" -align "center" -ann "More Scale, more wind apmlitude";
floatField -v 1 -w 48 -bgc 0.45 0.52 0.57 -precision 2 windScale;
text -label " Speed " -align "center" -ann "More Speed, more wind frequence";
floatField -v 1 -w 20 -precision 2 -bgc 0.45 0.52 0.57 windSpeed;
setParent..; setParent..; setParent..;
rowColumnLayout -nc 1;
string $theLayout =`frameLayout -cc OverlapperPanelBig -ec OverlapperPanelSmall -collapsable 1 - collapse 1 -l "Options"`;
checkBox -l "Don't use first controls" -v 0 -ann "Don't use first controls in selected sequence of controls" firstCtrl;
checkBox -l "Add translate" -v 0 -ann "Add translate overlap for selected controls" IKmode;
checkBox -l "Hierarchy" -v 0 -ann "Add all controls below the hierarchy. Works with Advanced Skeleton rigs" HierarchyCheckBox;
checkBox -l "Cycle" -v 0 -ann "Create seamless overlapping action for cycle animation. The first and the last keys on timeline must be the same" CycleCheckBox;
setParent..;
button -w 160 -label "Overlap" -bgc 0.85 0.85 0.85 -command "OverlapperStarter";
showWindow $window;
window -edit -widthHeight 163 163 OverlapperPanel;
}
global proc OverlapperPanelBig()
{window -edit -widthHeight 163 163 OverlapperPanel;}
global proc OverlapperPanelSmall()
{window -edit -widthHeight 163 236 OverlapperPanel;}
proc hIntro()
{launch -web "https://vimeo.com/286860063";}
proc hTutorial()
{launch -web "https://vimeo.com/287771379";}
global proc CleanUpProc()
{
if(`objExists "*_OverlapJoint*"`) {delete "*_OverlapJoint*";}
if(`objExists "*:*_OverlapJoint*"`) {delete "*:*_OverlapJoint*";}
if(`objExists "*:*:*_OverlapJoint*"`) {delete "*:*:*_OverlapJoint*";}
if(`objExists "*overlapOffsetLocator*"`) {delete "*overlapOffsetLocator*";}
if(`objExists "overlapResultLocatorOut*"`) {delete "overlapResultLocatorOut*";}
if(`objExists "TEMP_Offset_locator*"`) {delete ("TEMP_Offset_locator*");}
if(`objExists "*overlapOffsetIKLocator*"`) {delete "*overlapOffsetIKLocator*";}
if(`objExists "OverlapperSet"`) {delete "OverlapperSet";}
if(`objExists "OverlapperWorkSet"`) {delete "OverlapperWorkSet";}
progressWindow -endProgress;
}
global proc OverlapperStarter()
{
if(`objExists "OverlapperWorkSet"`){delete "OverlapperWorkSet";}
//time range
global string $gPlayBackSlider;
global float $timeStart, $timeEnd;
global float $timeStartGlobal, $timeEndGlobal;
float $RangeStart, $Range[];
$Range = `timeControl -q -ra $gPlayBackSlider`;
$RangeStart = $Range[1] - $Range[0];
if($RangeStart == 1)
{$timeStartGlobal = `playbackOptions -q -min`; $timeEndGlobal = `playbackOptions -q -max`;}
else
{$timeStartGlobal = $Range[0]; $timeEndGlobal = $Range[1];}
string $ctrlsAmount[] = `ls -sl`;
// MANY CONTROLS
if(`size($ctrlsAmount)`>1)
{
// some ctrls with hierarchy DONE!!!!!!
if (`checkBox -q -v HierarchyCheckBox`==1)
{
for ($SelCtrl in $ctrlsAmount)
{
select -r $SelCtrl; progressWindow -endProgress; OverlapperWithHierarchy; CycleFinal;
}
}
// some ctrls without hierarchy DONE!!!!!!
else
{
Overlapper; CycleFinal;
}
}
// ONE CONTROLS
else {
// with hierarchy DONE!!!!!!
if (`checkBox -q -v HierarchyCheckBox`==1)
{
progressWindow -endProgress; OverlapperWithHierarchy; CycleFinal;
}
// without hierarchy
else
{
confirmDialog -b "Ok" -t "Oooops.." -m "For correct work you should select more than one control \n or switch on Hierarchy mode in Options \n\nIf you want overlap one control: \n 1. select two neighboring controls \n 2. check `Don't use first control` in Options ";
}
}
}
////////////////// Hierarchy work //////////////////////
proc OverlapperWithHierarchy()
{
string $ArraySecondGuys[];
string $parentArray[];
string $nodesArray[];
string $Chain[];
string $lastElement;
string $allSceneNurbes[];
string $currentShapeType;
string $CtrlByHierarchy[];
string $TypeOfObject;
int $ClearElemwnts;
$ClearElemwnts = `size($allSceneNurbes)`; for ($s=0; $s<$ClearElemwnts; ++$s ){stringArrayRemoveAtIndex(0, $allSceneNurbes);}
// find type of selection
string $currentCtrls[] = `ls -sl`;
select -r $currentCtrls[0];
pickWalk -d down;
string $currentShape[] = `ls -sl`;
$currentShapeType = `objectType $currentShape[0]`;
select -r $currentCtrls; select -hi;
$currentCtrls = `ls -sl`;
if( `objExists "*Root_M"`||`objExists "*:Root_M"`||`objExists "*DeformationSystem"`||`objExists "*:DeformationSystem"`||`objExists "*MotionSystem"`||`objExists "*:MotionSystem"`||`objExists "*FitSkeleton"`||`objExists "*:FitSkeleton"`)
{$currentShapeType = "nurbsCurve";}
$allSceneNurbes = `listTransforms ("-type "+$currentShapeType)`;
string $Stuff[] = stringArrayRemove($allSceneNurbes, $currentCtrls);
$CtrlByHierarchy = stringArrayRemove($Stuff, $currentCtrls);
select -r $CtrlByHierarchy;
int $amountOfAllCtrls = `size($CtrlByHierarchy)`;
string $LastCtrlInHierarchy = $CtrlByHierarchy[(`size($CtrlByHierarchy)`)-1];
$ClearElemwnts = `size($Chain)`; for ($s=0; $s<$ClearElemwnts; ++$s ){stringArrayRemoveAtIndex(0, $Chain);}
for ($i=0; $i<$amountOfAllCtrls; ++$i )
{
select -r $CtrlByHierarchy[$i];
select -hi;
string $currentCtrls[] = `ls -sl`;
string $Stuff[] = stringArrayRemove($allSceneNurbes, $currentCtrls);
string $CurrentCtrlByHierarchy[] = stringArrayRemove($Stuff, $currentCtrls);
if ($CtrlByHierarchy[$i+1]==$CurrentCtrlByHierarchy[1]&&$CurrentCtrlByHierarchy[0]!=$LastCtrlInHierarchy)
{
stringArrayInsertAtIndex(100, $Chain, $CurrentCtrlByHierarchy[0]);
select -r $CurrentCtrlByHierarchy[0];
}
else
{
stringArrayInsertAtIndex(100, $Chain, $CurrentCtrlByHierarchy[0]);
select -r $Chain;
Overlapper;
string $CtrlByHierarchy[] = stringArrayRemove($Chain, $CtrlByHierarchy);
int $ClearElemwnts = `size($Chain)`;for ($s=0; $s<$ClearElemwnts; ++$s ){stringArrayRemoveAtIndex(0, $Chain);}
}
int $amountOfAllCtrls = `size($CtrlByHierarchy)`;
}
}
///////////// Overlapper /////////////
proc Overlapper()
{
cycleCheck -e off;
global float $timeStartGlobal, $timeEndGlobal;
global float $timeStart, $timeEnd;
$timeStart = $timeStartGlobal;
$timeEnd = $timeEndGlobal;
int $ClearElemwnts;
float $OverTimeShift = `floatField -q -v timeShift`;
float $OverGlobalScale = `floatField -q -v globalScale`; if($OverGlobalScale<=0){$OverGlobalScale=0.001;}
float $windScaleValue = `floatField -q -v windScale`;
float $windSpeedValue = `floatField -q -v windSpeed`;
int $deBugMode = `menuItem -query -cb debMode`;
int $onLayerSwitch = `menuItem -query -cb onLayerMode`;
int $adptScale = `menuItem -query -cb adScaleMode`;
int $OvSelectionSet = `menuItem -query -cb ovCrSelSet`;
int $TRANSLATEmode = `checkBox -q -v IKmode`;
int $useFirstCtrl = `checkBox -q -v firstCtrl`;
int $WindSwitch = `checkBox -q -v WindCheckBox`;
int $CycleCheckBox = `checkBox -q -v CycleCheckBox`;
float $timeShift = $OverTimeShift;
float $overlapIntensity = $OverGlobalScale;
float $scaleModulator = 5;
string $overlapJointsArray[];
float $overlapJointsLenghtArray[];
float $averageLenghtJoints;
global float $sumLenghtJoints;
string $ControlName[];
float $cycleLenghts;
string $SelectedControlsClearNameSpaces[];
string $SelectedControls[];
global string $eulerFilterCurves[];
$ClearElemwnts = `size($overlapJointsArray)`; for ($i=0; $i<$ClearElemwnts; ++$i ){stringArrayRemoveAtIndex(0, $overlapJointsArray);}
$ClearElemwnts = `size($overlapJointsLenghtArray)`; for ($i=0; $i<$ClearElemwnts; ++$i ) {floatArrayRemoveAtIndex(0, $overlapJointsLenghtArray);}
$ClearElemwnts = `size($SelectedControls)`; for ($i=0; $i<$ClearElemwnts; ++$i ) {stringArrayRemoveAtIndex(0, $SelectedControls);}
$ClearElemwnts = `size($SelectedControlsClearNameSpaces)`; for ($i=0; $i<$ClearElemwnts; ++$i ) {stringArrayRemoveAtIndex(0, $SelectedControlsClearNameSpaces);}
//time range
float $currentTime =`currentTime -query`;
//set frame
currentTime - e $timeStart;
$SelectedControls = `ls -sl`;
int $iLoop = `size($SelectedControls)`;
$DividedName = `tokenize $SelectedControls[0] ":" $ControlName`;
if ($DividedName>1)
{
for ($i=0; $i<$iLoop; ++$i)
{
$DividedNameCurve = `tokenize $SelectedControls[$i] ":" $ControlName`;
$ClearNameCtrl = $ControlName[($DividedNameCurve-1)];
stringArrayInsertAtIndex(100, $SelectedControlsClearNameSpaces, $ClearNameCtrl);
}
}
else {$SelectedControlsClearNameSpaces=$SelectedControls;}
select -cl;
//progressBar
int $amount = 0;
float $prAmount = 100/$iLoop;
progressWindow
-title "progress..."
-progress $amount
-status "Progress: 0%"
-isInterruptable true;
// create locators for Joints
for ($i=0; $i<$iLoop; ++$i)
{
spaceLocator -n ("TEMP_Offset_locator"+$i);
select -r $SelectedControls[$i] ("TEMP_Offset_locator"+$i);
parentConstraint -weight 1;
}
select -cl;
// create Joints
for ($i=0; $i<$iLoop; ++$i )
{
float $WorldTr[] = `xform -q -ws -t ("TEMP_Offset_locator"+$i)`;
joint -rad 1 -n ($SelectedControls[$i]+"_OverlapJoint") -p $WorldTr[0] $WorldTr[1] $WorldTr[2];
if ($i>0)
{
joint -e -zso -oj xyz -sao yup ($SelectedControls[$i-1]+"_OverlapJoint");
}
stringArrayInsertAtIndex( 100, $overlapJointsArray, ($SelectedControls[$i]+"_OverlapJoint") );
}
delete ("TEMP_Offset_locator*");
int $overlapJointsAnmount = `size($SelectedControls)`;
select -r ($overlapJointsArray[$overlapJointsAnmount-1]);
duplicate -rr;
string $LastOrientJoints[] = `ls -sl`;
move -r -ls -wd 2 0 0 ;
float $WorldLastTr[] = `xform -q -ws -t $LastOrientJoints[0]`;
select -r ($SelectedControls[$i-1]+"_OverlapJoint");
joint -rad 1 -n ($SelectedControls[$i-1]+"LastOrientJoint") -p $WorldLastTr[0] $WorldLastTr[1] $WorldLastTr[2];
joint -e -zso -oj xyz -sao yup ($SelectedControls[$i-1]+"_OverlapJoint");
delete $LastOrientJoints;
$LastOrientJoints = `ls -sl`;
stringArrayInsertAtIndex( 100, $overlapJointsArray, $LastOrientJoints[0]);
select -r $overlapJointsArray;
joint -e -oj xyz -secondaryAxisOrient zup -ch -zso;
$ClearElemwnts = `size($overlapJointsLenghtArray)`; for ($s=0; $s<$ClearElemwnts; ++$s ){floatArrayRemoveAtIndex(0, $overlapJointsLenghtArray);}
//joints lengths
for ($i=1; $i<($iLoop+1); ++$i )
{
float $DistanceBetween = `getAttr ($overlapJointsArray[$i]+".translateX")`;
floatArrayInsertAtIndex( 100, $overlapJointsLenghtArray, $DistanceBetween);
}
//average
int $JointsLentghtsAmount = `size($overlapJointsLenghtArray)`;
$sumLenghtJoints = 0;
for ($i=0; $i<($JointsLentghtsAmount); ++$i )
{
$sumLenghtJoints = $sumLenghtJoints + $overlapJointsLenghtArray[$i];
}
$averageLenghtJoints = ($sumLenghtJoints-2)/$JointsLentghtsAmount;
setAttr ($SelectedControls[$i-1]+"LastOrientJoint.translateX") $averageLenghtJoints;
// constrain joint to controls
for ($i=0; $i<$iLoop; ++$i )
{
select -r $SelectedControls[$i] ($SelectedControls[$i]+"_OverlapJoint");
pointConstraint -weight 1 -mo;
orientConstraint -weight 1 -mo;
}
// bake jonts
select -r $overlapJointsArray;
bakeResults
-simulation 0
-t ($timeStart+":"+$timeEnd)
-sampleBy 1
-disableImplicitControl 1
-preserveOutsideKeys 1
-sparseAnimCurveBake 1
-bakeOnOverrideLayer 0
-minimizeRotation 0
$overlapJointsArray;
delete -constraints;
// Cycling (copy curves, add time)
if ($CycleCheckBox == 1)
{
for ($i=0; $i<($iLoop-1); ++$i )
{
selectKey -r -k -t ($timeStart+":"+$timeEnd) ($SelectedControlsClearNameSpaces[$i]+"_OverlapJoint_translateX")
($SelectedControlsClearNameSpaces[$i]+"_OverlapJoint_translateY")
($SelectedControlsClearNameSpaces[$i]+"_OverlapJoint_translateZ")
($SelectedControlsClearNameSpaces[$i]+"_OverlapJoint_rotateX")
($SelectedControlsClearNameSpaces[$i]+"_OverlapJoint_rotateY")
($SelectedControlsClearNameSpaces[$i]+"_OverlapJoint_rotateZ");
copyKey;
pasteKey -time $timeEnd -float $timeEnd -option insert -copies 2 -connect 0 -timeOffset 0 -floatOffset 0 -valueOffset 0;
select -cl ;
}
$cycleLenghts = $timeEnd-$timeStart;
$timeEnd = $timeEnd+2*$cycleLenghts;
}
// Overlaping
for ($i=0; $i<$iLoop; ++$i )
{
//progressBar
$amount += $prAmount;
progressWindow -edit
-progress $amount
-status ("Progress: "+$amount+"%");
//create locator
spaceLocator -n ("overlapOffsetLocator"+$i);
select -r $overlapJointsArray[$i] ("overlapOffsetLocator"+$i);
string $temps[] = `pointConstraint -offset 0 0 0 -weight 1`;
delete $temps;
$temps = `orientConstraint -offset 0 0 0 -weight 1`;
delete $temps;
//create IK locator
spaceLocator -n ("overlapOffsetIKLocator"+$i);
select -r $overlapJointsArray[$i] ("overlapOffsetIKLocator"+$i);
$temps = `pointConstraint -offset 0 0 0 -weight 1`;
delete $temps;
$temps = `orientConstraint -offset 0 0 0 -weight 1`;
delete $temps;
select -r ("overlapOffsetLocator"+$i);
if ($adptScale==1){$scaleModulator = $averageLenghtJoints;}
float $overlapIntensityMult = $averageLenghtJoints/$overlapIntensity*5;
move -r -os -ls $overlapIntensityMult 0 0 ;
select -r $overlapJointsArray[$i] ("overlapOffsetLocator"+$i);
parentConstraint -mo -weight 1;
select -r $overlapJointsArray[$i] ("overlapOffsetIKLocator"+$i);
parentConstraint -mo -weight 1;
bakeResults -simulation 0
-t ($timeStart+":"+$timeEnd)
-sampleBy 1
-disableImplicitControl 1
-preserveOutsideKeys 1
-sparseAnimCurveBake 0
-removeBakedAttributeFromLayer 0
-removeBakedAnimFromLayer 0
-bakeOnOverrideLayer 0
-minimizeRotation 0
-controlPoints 0
-shape 1
("overlapOffsetLocator"+$i) ("overlapOffsetIKLocator"+$i);
filterCurve ("overlapOffsetLocator"+$i+"_rotateX")("overlapOffsetLocator"+$i+"_rotateY")("overlapOffsetLocator"+$i+"_rotateZ");
spaceLocator -n ("overlapOffsetLocatorWind"+$i);
parent ("overlapOffsetLocatorWind"+$i) ("overlapOffsetLocator"+$i);
makeIdentity -apply false -t 1 -r 1 -s 1;
float $timeShiftNeg = -1*$timeShift;
float $timeShiftCurrent = $timeShift+1;
keyframe -e -iub true -r -o over -tc $timeShift ("overlapOffsetLocator"+$i+"_translateX");
keyframe -e -iub true -r -o over -tc $timeShift ("overlapOffsetLocator"+$i+"_translateY");
keyframe -e -iub true -r -o over -tc $timeShift ("overlapOffsetLocator"+$i+"_translateZ");
keyframe -e -iub true -r -o over -tc $timeShift ("overlapOffsetIKLocator"+$i+"_translateX");
keyframe -e -iub true -r -o over -tc $timeShift ("overlapOffsetIKLocator"+$i+"_translateY");
keyframe -e -iub true -r -o over -tc $timeShift ("overlapOffsetIKLocator"+$i+"_translateZ");
keyframe -e -iub true -r -o over -tc $timeShift ("overlapOffsetLocator"+$i+"_rotateX");
keyframe -e -iub true -r -o over -tc $timeShift ("overlapOffsetLocator"+$i+"_rotateY");
keyframe -e -iub true -r -o over -tc $timeShift ("overlapOffsetLocator"+$i+"_rotateZ");
selectKey -add -k -t $timeShiftCurrent ("overlapOffsetLocator"+$i+"_translateX");
selectKey -add -k -t $timeShiftCurrent ("overlapOffsetLocator"+$i+"_translateY");
selectKey -add -k -t $timeShiftCurrent ("overlapOffsetLocator"+$i+"_translateZ");
selectKey -add -k -t $timeShiftCurrent ("overlapOffsetIKLocator"+$i+"_translateX");
selectKey -add -k -t $timeShiftCurrent ("overlapOffsetIKLocator"+$i+"_translateY");
selectKey -add -k -t $timeShiftCurrent ("overlapOffsetIKLocator"+$i+"_translateZ");
selectKey -add -k -t $timeShiftCurrent ("overlapOffsetLocator"+$i+"_rotateX");
selectKey -add -k -t $timeShiftCurrent ("overlapOffsetLocator"+$i+"_rotateY");
selectKey -add -k -t $timeShiftCurrent ("overlapOffsetLocator"+$i+"_rotateZ");
keyframe -animation keys -option over -relative -timeChange $timeShiftNeg;
spaceLocator -n ("overlapInLocator_first_"+$i);
spaceLocator -n ("overlapInLocator_second_"+$i);
spaceLocator -n ("overlapResultLocator_"+$i);
select -r ("overlapInLocator_first_"+$i) ($SelectedControls[$i]+"_OverlapJoint");
Parent;
select -r ("overlapInLocator_second_"+$i) ($SelectedControls[$i]+"_OverlapJoint");
Parent;
select -r ("overlapResultLocator_"+$i) ($SelectedControls[$i]+"_OverlapJoint");
Parent;
select -r ("overlapInLocator_first_"+$i) ("overlapInLocator_second_"+$i) ("overlapResultLocator_"+$i);
makeIdentity -apply false -t 1 -r 1 -s 1;
select -r("overlapInLocator_second_"+$i);
move -r -os -ls $overlapIntensityMult 0 0 ;
select -r ("overlapInLocator_first_"+$i);
group -n ("overlapInLocator_first_"+$i+"grp");
// IK mode
if($TRANSLATEmode==1)
{
select -r ("overlapOffsetIKLocator"+$i) ("overlapInLocator_first_"+$i+"grp");
pointConstraint -mo -weight 1;
}
select -r ("overlapOffsetLocatorWind"+$i) ("overlapInLocator_second_"+$i);
parentConstraint -mo -weight 1;
select -r ("overlapInLocator_second_"+$i) ("overlapInLocator_first_"+$i+"grp");
aimConstraint -mo -weight 1 -aimVector 1 0 0 -upVector 0 1 0 -worldUpType "object" -worldUpObject ("overlapInLocator_second_"+$i);
select -r ("overlapInLocator_second_"+$i) ("overlapInLocator_first_"+$i);
orientConstraint -mo -skip y -skip z -weight 1;
select -r ("overlapInLocator_first_"+$i) ("overlapResultLocator_"+$i);
parentConstraint -mo -weight 1;
///Wind
if($i<1&&$WindSwitch==1)
{
select -r overlapOffsetLocatorWind0;
string $WindFirstControl[] = `ls -sl`;
float $windMultiply = 0.07*$overlapIntensityMult*$windScaleValue ;
float $speedMultiply = 20/$windSpeedValue;
setKeyframe -attribute "translateY" -attribute "translateZ" -t $timeStart overlapOffsetLocatorWind0;
bakeResults
-simulation 0
-t ($timeStart+":"+($timeEnd+$speedMultiply))
-sampleBy $speedMultiply
-oversamplingRate 1
-disableImplicitControl true
-preserveOutsideKeys 1
-sparseAnimCurveBake false
-removeBakedAttributeFromLayer false
-removeBakedAnimFromLayer false
-bakeOnOverrideLayer false
-minimizeRotation true
-at "ty" -at "tz"
overlapOffsetLocatorWind0;
string $listAnimAttrs[] = `listAttr -k overlapOffsetLocatorWind0`;
for ($attr in $listAnimAttrs)
{
// array of animated atributes
string $animCurve[] = `listConnections -type "animCurve" ("overlapOffsetLocatorWind0."+$attr)`;
for ($animCurveCurrent in $animCurve)
{
// array of keys
float $animCurveCurrentKeysTimeArray[] = `keyframe -time ($timeStart+":"+$timeEnd) -query -timeChange $animCurveCurrent`;
// array of values
for ($animCurveCurrentKeysTime in $animCurveCurrentKeysTimeArray)
{
float $animCurveCurrentKeysTimeArray[] = `keyframe -time $animCurveCurrentKeysTime -query -valueChange $animCurveCurrent`;
//Randomazer
float $RandomizerValue = `rand -1 1`;
float $animCurveCurrentKeysValueArrayAddRandom = $animCurveCurrentKeysTimeArray[0]+$windMultiply*$RandomizerValue;
keyframe -e -iub true -r -o over -vc $animCurveCurrentKeysValueArrayAddRandom -t $animCurveCurrentKeysTime $animCurveCurrent;
}
}
}
keyframe -e -iub true -r -o over -tc ($speedMultiply/2) overlapOffsetLocatorWind0_translateY;
selectKey -add -k -t (($speedMultiply/2)+1) overlapOffsetLocatorWind0_translateY;
keyframe -animation keys -option over -relative -timeChange ($speedMultiply/-2);
}
bakeResults -simulation 0
-t ($timeStart+":"+$timeEnd)
-sampleBy 1
-disableImplicitControl 1
-preserveOutsideKeys 1
-sparseAnimCurveBake 0
-removeBakedAttributeFromLayer 0
-removeBakedAnimFromLayer 0
-bakeOnOverrideLayer 0
-minimizeRotation 0
-controlPoints 0
-shape 1
("overlapResultLocator_"+$i);
if($deBugMode==0) {delete ("overlapInLocator_first_"+$i) ("overlapInLocator_first_"+$i+"grp") ("overlapOffsetLocator"+$i) ("overlapInLocator_second_"+$i);}
spaceLocator -n ("overlapResultLocatorOut_"+$i);
if(`objExists "OverlapperOverlapResultLocatorSet"`) {sets -edit -forceElement OverlapperOverlapResultLocatorSet ("overlapResultLocatorOut_"+$i);}
else {$createSetResult = `sets -name "OverlapperOverlapResultLocatorSet"`;}
select -r ("overlapResultLocator_"+$i) ("overlapResultLocatorOut_"+$i);
parentConstraint -weight 1;
bakeResults -simulation 0
-t ($timeStart+":"+$timeEnd)
-sampleBy 1
-disableImplicitControl 1
-preserveOutsideKeys 1
-sparseAnimCurveBake 0
-removeBakedAttributeFromLayer 0
-removeBakedAnimFromLayer 0
-bakeOnOverrideLayer 0
-minimizeRotation 0
-controlPoints 0
-shape 1
("overlapResultLocatorOut_"+$i);
if($deBugMode==0) {delete ("overlapResultLocator_"+$i);}
select -r ("overlapResultLocatorOut_"+$i) ($SelectedControls[$i]+"_OverlapJoint");
parentConstraint -weight 1 -mo;
}
// constrain controls back to joint
if ($useFirstCtrl==1)
{
for ($i=1; $i<$iLoop; ++$i )
{
//orient constraint
if (`getAttr -keyable ($SelectedControls[$i]+".rx")`==1&&`getAttr -lock ($SelectedControls[$i]+".rx")`==0&&
`getAttr -keyable ($SelectedControls[$i]+".ry")`==1&&`getAttr -lock ($SelectedControls[$i]+".ry")`==0&&
`getAttr -keyable ($SelectedControls[$i]+".rx")`==1&&`getAttr -lock ($SelectedControls[$i]+".rx")`==0)
{select -r ($SelectedControls[$i]+"_OverlapJoint") $SelectedControls[$i]; orientConstraint -mo -weight 1;}
//point constraint
if (`getAttr -keyable ($SelectedControls[$i]+".tx")`==1&&`getAttr -lock ($SelectedControls[$i]+".tx")`==0&&
`getAttr -keyable ($SelectedControls[$i]+".ty")`==1&&`getAttr -lock ($SelectedControls[$i]+".ty")`==0&&
`getAttr -keyable ($SelectedControls[$i]+".tx")`==1&&`getAttr -lock ($SelectedControls[$i]+".tx")`==0)
{pointConstraint -mo -weight 1;}
}
}
else
{
for ($i=0; $i<$iLoop; ++$i )
{
//orient constraint
if (`getAttr -keyable ($SelectedControls[$i]+".rx")`==1&&`getAttr -lock ($SelectedControls[$i]+".rx")`==0&&
`getAttr -keyable ($SelectedControls[$i]+".ry")`==1&&`getAttr -lock ($SelectedControls[$i]+".ry")`==0&&
`getAttr -keyable ($SelectedControls[$i]+".rx")`==1&&`getAttr -lock ($SelectedControls[$i]+".rx")`==0)
{select -r ($SelectedControls[$i]+"_OverlapJoint") $SelectedControls[$i]; orientConstraint -mo -weight 1;}
//point constraint
if (`getAttr -keyable ($SelectedControls[$i]+".tx")`==1&&`getAttr -lock ($SelectedControls[$i]+".tx")`==0&&
`getAttr -keyable ($SelectedControls[$i]+".ty")`==1&&`getAttr -lock ($SelectedControls[$i]+".ty")`==0&&
`getAttr -keyable ($SelectedControls[$i]+".tx")`==1&&`getAttr -lock ($SelectedControls[$i]+".tx")`==0)
{pointConstraint -mo -weight 1;}
}
}
if ($CycleCheckBox == 1)
{
$timeStart = `playbackOptions -q -min`;
$timeEnd = `playbackOptions -q -max`;
$cycleLenghts = $timeEnd-$timeStart;
select -r OverlapperOverlapResultLocatorSet;
string $EulerArrays[] = `ls -sl`;
for ($obj in $EulerArrays)
{
keyframe -e -iub true -r -o over -tc (-2*$cycleLenghts) ($obj+"_translateX");
keyframe -e -iub true -r -o over -tc (-2*$cycleLenghts) ($obj+"_translateY");
keyframe -e -iub true -r -o over -tc (-2*$cycleLenghts) ($obj+"_translateZ");
keyframe -e -iub true -r -o over -tc (-2*$cycleLenghts) ($obj+"_rotateX");
keyframe -e -iub true -r -o over -tc (-2*$cycleLenghts) ($obj+"_rotateY");
keyframe -e -iub true -r -o over -tc (-2*$cycleLenghts) ($obj+"_rotateZ");
}
}
select -r $SelectedControls;
$timeStart = `playbackOptions -q -min`;
$timeEnd = `playbackOptions -q -max`;
bakeResults
-simulation 0
-t ($timeStart+":"+$timeEnd)
-sampleBy 1
-disableImplicitControl 1
-preserveOutsideKeys 1
-sparseAnimCurveBake 0
-removeBakedAttributeFromLayer 0
-removeBakedAnimFromLayer 0
-bakeOnOverrideLayer $onLayerSwitch
-minimizeRotation 0
-controlPoints 0
-shape 1
$SelectedControls;
//create selection set
if($OvSelectionSet==1)
{
if(`objExists "OverlapperSet*"`) {sets -edit -forceElement OverlapperSet $SelectedControls;}
else {$createSetResult = `sets -name "OverlapperSet"`;}
}
if(`objExists "OverlapperWorkSet*"`) {sets -edit -forceElement OverlapperWorkSet $SelectedControls;}
else {$createSetResult = `sets -name "OverlapperWorkSet"`;}
// finalization
if($deBugMode==0) {delete $overlapJointsArray "overlapResultLocatorOut*" "*overlapOffsetIKLocator*";}
currentTime - e $currentTime;
select -r $SelectedControls;
cycleCheck -e on;
progressWindow -endProgress;
// select ovelapped controls set
if(`objExists "OverlapperSet"`) {select -r OverlapperSet;}
}
// Finalizing
global proc CycleFinal()
{
string $SelectedControlsClearNameSpaces[];
string $SelectedControls[];
global string $eulerFilterCurves[];
string $ControlName[];
float $cycleLenghts;
// euler all anim curves
$ClearElemwnts = `size($eulerFilterCurves)`; for ($s=0; $s<$ClearElemwnts; ++$s ){stringArrayRemoveAtIndex(0, $eulerFilterCurves);}
select -r OverlapperWorkSet;
string $EulerArrays[] = `ls -sl`;
for ($obj in $EulerArrays)
{
$listAnimAttrs = `listAttr -k $obj`;
for ($attr in $listAnimAttrs)
{
$animCurve = `listConnections -type "animCurve" ($obj+"."+$attr)`;
int $ClearElemwnts = `size($animCurve)`;
appendStringArray($eulerFilterCurves, $animCurve, $ClearElemwnts);
}
}
filterCurve $eulerFilterCurves;
delete "OverlapperWorkSet";
}
OverlapperRelease; |
加载中...
搜索
≮泠悾芞卐
cgpig
570753200
提升卡
置顶卡
沉默卡
喧嚣卡
变色卡
显身卡
